Compact Low-Voltage and High-Speed CMOS, BiCMOS and Bipolar Operational Amplifiers
-
- Hardcover
- Taschenbuch ausgewählt
- eBook
-
Sprache:Englisch
185,99 €
UVP
213,99 €
inkl. gesetzl. MwSt.,
Beschreibung
Produktdetails
Einband
Taschenbuch
Erscheinungsdatum
07.12.2010
Verlag
Springer UsSeitenzahl
250
Maße (L/B/H)
23,5/15,5/1,5 cm
Gewicht
412 g
Auflage
Softcover reprint of hardcover 1st ed. 1999
Sprache
Englisch
ISBN
978-1-4419-5102-1
The book presents efficient circuit topologies in order to combine high performance with simple solutions. In total twelve amplifier realizations are discussed. Two bipolar amplifiers are discussed, a 1-GHz operational amplifier and an amplifier with a high ratio between the maximum output current and the quiescent current. Five amplifiers have been designed in CMOS technology, extremely compact circuits that can operate on supply voltages down to one gate-source voltage and two saturation voltages which equals about 1.4 V and, ultimate-low-voltage amplifiers that can operate on supply voltages down to one gate-source voltage and one saturation voltage which amounts to about 1.2 V. In BiCMOS technology five amplifiers have been designed. The first two amplifiers are based on a compact topology. Two other amplifiers are designed to operate on low supply voltages down to 1.3 V. The final amplifier has a unity-gain frequency of 200 MHz and can operate down to 2.5 V.
Compact Low-Voltage and High-Speed CMOS, BiCMOS and Bipolar Operational Amplifiers is intended for the professional analog designer. Also, it is suitable as a text book for advanced courses in amplifier design.
